REF: 806CSM111810

Description:

The Prevost CSM111810 quick-connect fitting for 10 mm tubing, made of stainless steel, is designed for high-flow pneumatic installations, guaranteeing maximum safety, durability, and performance in demanding industrial environments.

safe shutter system and is fully compatible with the ISO 6150C profile.

Features

• Quick coupling for Ø10 mm tube.
• Made in high resistance stainless steel.
• High flow rate P=11.
• Security shutter system.
• Excellent resistance to corrosion and wear.
• Suitable for intensive industrial use.
• Compatible with ISO 6150C profile.

Technical Specifications

• Brand: Prevost
• Reference: CSM111810
• Type: Quick coupling for tube
• Tube diameter: Ø10 mm
• Profile: ISO 6150C
• Material: Stainless steel
• Ø passage: 11 mm
• Debit: 4120 l/min (P = 6 bar, ΔP = 0.6 bar)
• Maximum operating pressure: 16 bar
• Security system: Shutter
