REF: 105M0089

High Capacity and Millimeter Precision in Structures

Industrial punching die with oblong geometry of 13x27 mm, compatible with Type 6 series die holder systems. It has a technical clearance of 0.7 mm, designed for the manufacture of adjustable joints and large-format slides.

Technical Specifications

• Model Reference: M6O1370x2770.

• Shape: Oblong / Coliso (Oval).

• Nominal Dimensions: 13 mm x 27 mm.

• Cutting Clearance (H): 0.7 mm.

• Tooling Type: Nº6.

• Application: Industrial punching and cutting of carbon and stainless steel sheets, plates and profiles.
