REF: 768320375A

Product Description: Precision Measurement in the Intermediate Range

The INSIZE 3203-75A outside micrometer is a high-precision measuring instrument designed for the dimensional control of parts between 50 and 75 mm. It is an indispensable tool in grinding, die-making, and turning shops, where verifying critical tolerances is a daily standard.

Key Features

• Superior Durability: Equipped with carbide (hard metal) measuring faces, ensuring permanent flatness and extreme resistance to wear from friction.
• Guaranteed Repeatability: Its ratchet stop system ensures that all measurements are taken with the same contact pressure, eliminating variations between different operators.
• DIN 863-1 Certification: This micrometer strictly complies with international manufacturing standards, ensuring a maximum deviation of only ±2 mm.
• Verification Standard Included: Since the range starts at 50 mm, the equipment is supplied with its corresponding zeroing standard to ensure accurate zeroing before starting work.

Technical Specifications

• Reference: 3203-75A
• Measuring Range: 50 - 75 mm
• Graduation: 0.01 mm (Metric) / 0.0001" (Imperial)
• Accuracy: 2 microns
• Technical Dimensions:
• L (Arc Length): 82 mm
• a (Depth): 15 mm
• b (Throat): 49 mm
